| Material | Messing vernickelt |
| Formdichtung | FKM |
| Material O-Ring | FKM |
| Schutzart | IP 68 - 1bar/30min |
| Temperaturbereich | -25°C bis +200°C |
| Variante |
PG, Metr. |
Außengewinde (AG) AG | Kabeldurchmesser Kabel-Ø | Gewindelänge (GL) (mm) GL (mm) | Höhe (H) (mm) H (mm) | Schlüsselweite (SW1/SW2) SW1/SW2 | Art.-Nr. |
|---|---|---|---|---|---|
| Zurücksetzen | |||||
| PG 7 | 5 – 7 mm | 6 | 16 | 14/14 mm | 1.106.0700.80 |
| PG 9 | 6 – 8 mm | 6 | 17 | 18/18 mm | 1.106.0900.80 |
| PG 9 | 7 – 10 mm | 6 | 17 | 18/18 mm | 1.106.0901.80 |
| M12 x 1,5 | 4 – 6 mm | 5 | 18 | 14/14 mm | 1.106.1200.58 |
| M16 x 1,5 | 7 – 9 mm | 5 | 19 | 18/18 mm | 1.106.1600.58 |
| M20 x 1,5 | 10 – 13 mm | 6 | 21 | 22/22 mm | 1.106.2000.58 |
| M25 x 1,5 | 15 – 18 mm | 7 | 23 | 28/28 mm | 1.106.2500.58 |
