| Connection size 1 (AG1) | G 3/4 |
| Connection type 1 (AT1) |
Hose connection, Internal thread |
| Length (L) | 26.4 mm |
| Width (B) | 14.4 mm |
| Height (H) | 33 mm |
| Wrench size 1 (SW1) | 30 mm |
| Suitable for |
Hose size 1/2", HUMMEL FE- and SFE-valve |
| Material | Brass blank |
| Material moulded seal | EPDM |
| Max. operating pressure | 10 bar |
| Max. operating temperature heating | 90 °C |
