News from the product line cable gland

Cable glands plastic

• Material: Polyamide V0 according to UL 94
• Sizes: M12 – M63, PG 7 – PG 48, NPT 3/8" – NPT 1 1/2"
• Overlapping clamping plates
• Chambered moulded seal
• Various connection thread lengths
• PVDF version available
• HSK-K black according to UL 746C f1
• Delivery colours grey, black, blue
• Also with multi- and flat cable insert

To the product plastic cable glands

Cable glands metal

• Material: nickel-plated brass
• Sizes: M6 - M110
• Overlapping clamping plates
• Chambered moulded seal
• Various connection thread lengths
• PVDF version available
• Inner sealing edge ensures optimum tightness
• Torsion protection

To the product metal cable glands

Cable glands for special applications

• Cable glands according to Hygienic Design
• VariaPro Rail: Cable gland for the railway sector
• VariaPro Temp: for applications under extreme temperatures
• VariaPro FKM: acid-resistant fitting for the process industry

more information about cable glands for special applications

Ex cable glands

• What is meant by explosion protection?
• Plastic cable glands for the Ex e area
• Metal cable glands for the Ex e area
• Cable glands for the Ex d area

---

HSK-K-Ex-Active:

• Material: polyamide
• Sizes: M12 – M63, NPT 3/8" – NPT 1 1/2"
• Type of protection Ex e according to EN 60079-0 and EN 60079-7
• Latest approvals according to ATEX and IECEx standards
• Halogen-free
• Can be used in zone 1 and zone 20
• Also with multi- and flat cable insert

---

HSK-M-Ex:

• Material: nickel-plated brass, INOX 1.4305
• Sizes: M12 – M63, PG 7 – PG 48, NPT 3/8" – NPT 1"
• Type of protection Ex e according to EN 60079-0 and EN 60079-7
• EMC, PVDF and MZ versions available
• Various connection thread lengths
• Also with multi- and flat cable insert

---

HSK-M-Ex-d:

• Material: nickel-plated brass, INOX 1.4404
• Sizes: M12 – M40, NPT 3/8" – NPT 1 1/2"
• Type of protection Ex d according to EN 60079-0 and EN 60079-1
• Various connection threads in metric and NPT
• MZ versions available (extra strain relief)

more information about ex cable glands

Cable glands EMC

Please accept marketing-cookies to watch this video.

• Material: nickel-plated brass, INOX 1.4305 & 1.4404
• Quick and easy installation
• 360° shield connection
• EMC background knowledge: Guidelines and laws

---

• HSK-M-EMC: low-cost variant for reliable EMC protection
• HSK-M-EMC-D with variable EMC connection: Premium version for best EMC protection
• Metrica-M-EMC-E: short assembly time due to the EMC spring
• To the cable glands EMC

more information about cable glands EMC
