| Connection size 1 (AG1) | G 3/4 |
| Connection type 1 (AT1) | Internal thread |
| Length (L) | 26.4 mm |
| Width (B) | 26.4 mm |
| Height (H) | 13.7 mm |
| Thread Length 1 (GL1) | 7.3 mm |
| Wrench size 1 (SW1) | 30 mm |
| Suitable for | HUMMEL FE ball valves |
| Type | Abdeckkappe |
| Material | Nickel-plated brass |
| Max. operating pressure | 10 bar |
| Max. operating temperature heating | 90 °C |
