| Connection size 1 (AG1) | G 3/8 |
| Connection type 1 (AT1) | External thread |
| Length (L) | 32 mm |
| Width (B) | 32 mm |
| Height (H) | 29.5 mm |
| Thread Length 1 (GL1) | 12.5 mm |
| Wrench size 1 (SW1) | 18 mm |
| Suitable for | Heating |
| d | 12.5 mm |
| Material | Nickel-plated brass |
| Material body/spindle | Nickel-plated brass |
| Material spindle | Nickel-plated brass |
| Max. operating pressure | 10 bar |
| Max. operating temperature heating | 130 °C |
