| Connection size 2 (AG2) | G 3/4 |
| Connection type 1 (AT1) | External thread (metric) |
| Connection type 2 (AT2) | Hose connection |
| Length (L) | 52.2 mm |
| Width (B) | 24 mm |
| Height (H) | 59 mm |
| Wrench size 1 (SW1) | 10 mm |
| Wrench size 2 (SW2) | 6 mm |
| Colour | black |
| Material moulded seal | EPDM |
| Material plastic cap | PA |
| Material body/spindle | Brass blank |
| Material retaining strap | |
| Material spindle | Brass blank |
| Material | Brass blank |
| Max. operating pressure | 10 bar |
| Max. operating temperature heating | 90 °C |
