| Connection size 1 (AG1) | G 3/4 |
| Connection size 2 (AG2) | G 3/4 |
| Connection type 1 (AT1) | Internal thread |
| Connection type 2 (AT2) | Internal thread |
| Connection type 4 (AT4) | External thread |
| Variable length (Lv) | 95 – 200 mm |
| Width (B) | 33.5 mm |
| Height (H) | 33.5 mm |
| Mounting form | Straight-type |
| Wrench size 1 (SW1) | 30 mm |
| Wrench size 2 (SW2) | 30 mm |
| Wrench size 3 (SW3) | 21 mm |
| Material | Stainless steel |
| Material moulded seal | AFM |
| Material union nut | Nickel-plated brass |
| Material corrugated tube | Stainless steel |
| Max. operating pressure | 6 bar |
| Max. operating temperature heating | 95 °C |
| max. bending radius | 50 mm |
| Bursting pressure | 80 bar |
| max. rate of flow | 2200 l/h |
