| Connection size 1 (AG1) | G 3/4 |
| Connection size 2 (AG2) | G 3/4 |
| Connection type 1 (AT1) | Euro cone |
| Connection type 2 (AT2) | Euro cone |
| Length (L) | 66 mm |
| Width (B) | 33.5 mm |
| Height (H) | 58 mm |
| Thread Length 1 (GL1) | 7.55 mm |
| Wrench size 1 (SW1) | 30 mm |
| Version | Nipple |
| Suitable for | Euro cone |
| Axial dimension (AM) | 40 mm |
| Mounting form | Y-piece |
| Kvs-value | 3.3 |
| Material | Nickel-plated brass |
| Material moulded seal | EPDM |
| Material union nut | Nickel-plated brass |
| Material body/union nut | Nickel-plated brass |
| Material connection nipple | Brass blank |
| Max. operating pressure | 10 bar |
| Max. operating temperature heating | 120 °C |
