| Mounting form | Straight-type |
| Connection size 1 (AG1) | M30 x 1,5 |
| Connection type 1 (AT1) | Internal thread |
| Length (L) | 76 mm |
| Width (B) | 42.5 mm |
| Height (H) | 42.5 mm |
| Colour | white |
| Material thermostatic head | ABS / PA |
| Material union nut | Nickel-plated brass |
| Frost protection device | Yes |
| Position 0 | Radiator closed |
| Position 1-5 | limited at respective temperature setting |
| Control range | 8 – 28 °C |
| max. Sensor temperature | 50 °C |
| Suitable for | Heating |
| Differential pressure influence | 0.3 |
| Hysteresis | 0.56 |
| Set point range | 1 - 5 |
| Setpoint 3 | 20 °C |
| Water temperature influence | 0.64 K |
| Position MAX | Max. sensor temperature 50°C |
| Position Snowflake | Frost protection setting |
| Control element | Solid sensor |
| Closing time | 19 min |
| Internal thread (IG) | M30 x 1,5 |
| RAL | 9016 |
| DIN | EN 215 |
