| Colour | white |
| Connection size 1 (AG1) | G 3/4 |
| Connection size 2 (AG2) | G 1/2 |
| Connection size 3 (AG3) | M30 x 1,5 |
| Connection type 1 (AT1) | Euro cone |
| Connection type 2 (AT2) | External thread |
| Connection type 3 (AT3) | Thermostatic valve |
| A1 | 26 mm |
| Length (L) | 178 mm |
| Width (B) | 46.8 mm |
| Height (H) | 80 mm |
| Thread Length 1 (GL1) | 8.2 mm |
| Wrench size 1 (SW1) | 30 mm |
| Wrench size 2 (SW2) | 30 mm |
| Wrench size 3 (SW3) | 34 mm |
| Version | Nipple |
| Suitable for | Thermostatic heads with connection thread M30 x 1.5 |
| Mounting form |
Corner type, Straight-type |
| Pipe system | Two pipe system |
| Axial dimension (AM) | 50 mm |
| Kvs-value | 1.9 |
| Material | Nickel-plated brass |
| Material moulded seal | EPDM / Teflon |
| Material union nut | Nickel-plated brass |
| Material body/union nut | Nickel-plated brass |
| Material connection nipple | Nickel-plated brass |
| Material cone insert | Brass blank |
| Max. operating pressure | 10 bar |
| Max. operating temperature heating | 90 °C |
| Thermostat connection | M30 x 1.5 |
