| Connection size 1 (AG1) | M22 x 1,5 |
| Connection size 2 (AG2) | G 3/4 |
| Connection type 1 (AT1) | External thread |
| Connection type 2 (AT2) | Euro cone |
| Axial dimension (AM) | 7,5 mm |
| A1 | 7.5 mm |
| Length (L) | 33.5 mm |
| Width (B) | 33.5 mm |
| Height (H) | 32.6 mm |
| Thread Length 1 (GL1) | 10 mm |
| Wrench size 1 (SW1) | 30 mm |
| Mounting form | Eccentric |
| Internal thread (IG) | G 3/4" |
| Material | Nickel-plated brass |
| Material moulded seal | EPDM |
| Material body | Nickel-plated brass |
| Material body/union nut | Nickel-plated brass |
| Material union nut | Nickel-plated brass |
| Max. operating pressure | 10 bar |
| Max. operating temperature heating | 120 °C |
