| Material | Nickel-plated brass |
| Material o-ring | FKM |
| Protection class |
IP68 - 10bar/30min, IP 69 K |
| Ex-protection level |
II 1D Ex ta IIIC Da, II 2G Ex db eb IIC Gb |
| Temperature range | -20°C to +180°C |
| Tightening torque | 8 Nm |
| Variant | Metric |
| External thread (AG) | M20 x 1,5 |
| Thread length (GL) | 16 mm |
| Height (H) | 19.5 mm |
| Wrench size (SW) | 22 mm |
| Product group | Accesories |
