| Material | Nickel-plated brass |
| Material o-ring | NBR |
| Protection class |
IP 68 – 10 bar, IP 69 K |
| Ex-protection level |
II 1D Ex ta IIIC Da, II 2G Ex eb IIC Gb |
| Temperature range | -20°C to +95°C |
| Tightening torque | 16 Nm |
| Variant | Metric |
| External thread (AG) | M40 x 1,5 |
| Internal thread (IG) | M32 x 1,5 |
| Thread length (GL) | 9 mm |
| Height (H) | 13.5 mm |
| Wrench size (SW) | 43 mm |
| Product group | Accesories |
