| Material | Polyamide |
| Seal | NBR |
| Protection class |
IP 54, IP 68 with additional O-ring:IP68 - 10bar/30min, IP 69 K |
| Temperature range | -40°C to +100°C |
| Colour | black |
| RAL | 9005 |
| Variant | Metric |
| External thread (AG) | M20 |
| Cable diameter | 6 – 12 mm |
| D | 25 mm |
| Thread length (GL) | 10 mm |
| Height (H) | 44 mm |
| Wrench size (SW) | 24 mm |
| Suitable for polyamide hose DN | 12 |
