| Colour cable | black |
| Locking type | Screw |
| Cable length | 2000 mm |
| Cable side 1 | M12, male, straight |
| Cable side 2 | open |
| Version cable | multicore |
| Cross section | 1.5 – 1.5 mm² |
| Protection class |
IP 69 K, IP 67, IP 65 |
| Shield | shielded |
| Insert | Pin |
| Seal type | O-Ring |
| Material seals/o-rings | FKM (FPM) |
| Material insulating body | PBT |
| Material cable sheath | PUR |
| Color contact insert | dark grey |
| Temperature range | -40°C to +125°C |
| Coding | T |
| Number of poles | 4 |
| Pole picture | 4 |
| Number of contacts power | 4 |
| Nominal current power | 12 A |
| Nominal voltage at degree of pollution 3 power | 63 V~ |
| Test voltage power | 840 V~ |
| Insulation resistance power | 10^9 Ω |
| max. contact resistance power | < 3 mOhm |
