| Housing type | Panel angled |
| Material housing | Zinc Die Cast |
| Material housing surface | blue passivated |
| Installation type | Rear wall |
| Version |
Screw, TWILOCK, right angled, rotatable |
| External thread plug-in side | M16 x 0,75 |
| Locking type |
Screw, TWILOCK |
| Material seals/o-rings |
FKM (FPM), NBR |
| Rotatable | 315 ° |
| Flange | 25 x 25 mm |
| Hole distance | 19.8 mm |
| Hole diameter | 4 x Ø 2,7 mm |
| Allen key/Torx | T10 |
| Protection class |
IP 67, IP 69 K |
| Temperature range | -40°C to +125°C |
