| Characteristic of connection | Crimp |
| Number of poles | 3 |
| Pole picture | 3 |
| Insert | Pin |
| Color contact insert | white |
| Material insulating body |
PA 6, PBT |
| Number of contacts power | 3 |
| Contact-Ø power | 1 mm |
| Nominal current power | 8 A |
| Nominal voltage at degree of pollution 3 power | 250 V~ |
| Insulation resistance power | > 10^8 Ω |
| max. contact resistance power | 3 mOhm |
| Temperature range | -40°C to +125°C |
| Degree of Protection | 3 |
| Flammability | V-0 (UL 94) |
| Suitable power contacts | 7010901001 |
