| Material housing | Copper-Zinc alloy |
| Material housing surface | Nickel |
| Insert |
Pin, Socket |
| Version | with vibration protection |
| External thread plug-in side | M27 x 1 |
| Locking type | Screw |
| Shield | unshielded |
| Seal type | O-Ring |
| Material seals/o-rings | NBR |
| Coding position | |
| Panel hole | Ø 23 + 0,1 mm |
| Flange | 30 x 30 mm |
| Hole distance | 23 mm |
| Hole diameter | 4 x Ø 3,2 mm |
| Length (L) | 25 mm |
| Protection class |
IP 67, IP 69 K |
| Temperature range | -40°C to +125°C |
