Housing type | Coupler |
Material housing |
brass, Zinc Die Cast |
Material housing surface | Nickel |
Insert | Pin |
Version | Screw |
External thread plug-in side | M40 x 1,5 |
Knurled screw-Ø plug-in side | 40 mm |
Locking type | Screw |
Shield | shielded |
Seal type | O-Ring |
Material seals/o-rings |
FKM (FPM), NBR |
Wrench size (SW1/SW2) | 40/38 mm |
Cable diameter | 21 – 28 mm |
Length (L) | 118 mm |
Temperature range | -40°C to +125°C |
Degree of Protection | 3 |
Protection class |
IP 67, IP 69 K |
Characteristic of connection | Crimp |
Number of poles | 6 |
Pole picture | 2 + 3 + PE |
Color contact insert | blue |
Material insulating body | PBT |
Number of contacts signal | 2 |
Number of contacts power | 3 |
Number of contacts PE | 1 |
Contact-Ø signal | 2 mm |
Contact-Ø power | 3.6 mm |
Terminal cross section signal | 0,14 – 1,5 mm² |
Terminal cross section power | 2,5 – 16 mm² |
Crimp range | 0.14 – 16 mm² |
Nominal current signal | 28 A |
Nominal current power | 55 A |
Nominal voltage at degree of pollution 3 signal | 300 V~ |
Nominal voltage at degree of pollution 3 power | 600 V~ |
Test voltage signal | 2500 V~ |
Test voltage power | 4000 V~ |
Insulation resistance signal | > 10^13 Ω |
Insulation resistance power | > 10^13 Ω |
max. contact resistance signal | 3 mOhm |
max. contact resistance power | 1 mOhm |
Minimum mating cycles | > 500 |
Suitable Signal contacts | 7015952001 |
Suitable power contacts |
7015953601, 7015953611, 7015953621, 7015953622, 7015953631 |
Suitable PE-/FE-contacts |
7015953601, 7015953611, 7015953621, 7015953623, 7015953631 |
