| Material housing | Copper-Zinc alloy |
| Material housing surface | Nickel |
| Insert | Pin |
| Installation type | Front wall |
| Version | for pin inserts |
| External thread plug-in side | M40 x 1,5 |
| Locking type | Screw |
| Shield | unshielded |
| Seal type | O-Ring |
| Material seals/o-rings |
FKM (FPM), NBR |
| Panel hole | Ø 40,2 + 0,1 mm |
| Length (L) | 62.5 mm |
| Wrench size (SW) | 28 mm |
| Temperature range | -40°C to +125°C |
| Degree of Protection | 3 |
| Protection class |
IP 67, IP 69 K |
| Characteristic of connection | Crimp |
| Number of poles | 6 |
| Pole picture | 2 + 3 + PE |
| Color contact insert | blue |
| Material insulating body | PBT |
| Number of contacts signal | 2 |
| Number of contacts power | 3 |
| Number of contacts PE | 1 |
| Contact-Ø signal | 2 mm |
| Contact-Ø power | 3.6 mm |
| Terminal cross section signal | 0,14 – 1,5 mm² |
| Terminal cross section power | 2,5 – 16 mm² |
| Crimp range | 0.14 – 16 mm² |
| Nominal current signal | 28 A |
| Nominal current power | 55 A |
| Nominal voltage at degree of pollution 3 signal | 300 V~ |
| Nominal voltage at degree of pollution 3 power | 600 V~ |
| Test voltage signal | 2500 V~ |
| Test voltage power | 4000 V~ |
| Insulation resistance signal | > 10^13 Ω |
| Insulation resistance power | > 10^13 Ω |
| max. contact resistance signal | 3 mOhm |
| max. contact resistance power | 1 mOhm |
| Minimum mating cycles | > 500 |
| Suitable Signal contacts | 7015952001 |
| Suitable power contacts |
7015953601, 7015953611, 7015953621, 7015953622, 7015953631 |
| Suitable PE-/FE-contacts |
7015953601, 7015953611, 7015953621, 7015953623, 7015953631 |
