| Material | Nickel-plated brass |
| Clamping insert | PVDF |
| Seal | FKM |
| Material o-ring | FKM |
| Protection class |
IP68 - 10bar/30min, IP 69 K |
| Ex-protection level |
II 1D Ex ta IIIC Da, II 2G Ex eb IIC Gb |
| Type Rating by |
4, 4X, 6, UL 50E |
| Variant | PG |
| External thread (AG) | PG 9 |
| Cable diameter | 4 – 8 mm |
| Thread length (GL) | 6 mm |
| Height (H) | 21 mm |
| Wrench size (SW1/SW2) | 17/17 mm |
| Temperature range | -20°C to +130°C |
| Tightening torque | 6 Nm |
| Product group |
EMC, Ex e |
