| Material | Nickel-plated brass |
| Seal | TPE |
| Material o-ring | NBR |
| Protection class | IP 68 - 1bar/30min |
| Variant | Metric |
| External thread (AG) | M8 x 0,75 |
| Cable diameter | 2 – 4,5 mm |
| Cable diameter | 2 – 4,5 mm |
| Thread length (GL) | 3.5 mm |
| Height (H) | 14.3 mm |
| Wrench size (SW1/SW2) | 11/11 mm |
| Temperature range | -20°C to +100°C |
| Tightening torque | 2 Nm |
| Product group | Standard |
