| Material | Polyamide |
| Temperature range | -40°C to +80°C |
| Tightening torque | 3 Nm |
| Colour | grey |
| RAL | 7035 |
| Variant | Metric |
| External thread (AG) | M16 x 1,5 |
| Internal thread (IG) | M12 x 1,5 |
| Type | A |
| Thread length (GL) | 9 mm |
| Height (H) | 16 mm |
| D | 24 mm |
| Wrench size (SW) | 22 mm |
| Product group | Accesories |
