| Material | Polyamide |
| Seal | NBR |
| Protection class |
IP 54, IP 68 with additional O-ring, IP 69 K |
| Temperature range | -40°C to +100°C |
| Colour | black |
| RAL | 9005 |
| Variant | NPT |
| External thread (AG) | NPT 1/2" |
| Cable diameter | 10 – 14 mm |
| D | 29 mm |
| Thread length (GL) | 13 mm |
| Height (H) | 46 mm |
| Wrench size (SW) | 27 mm |
| Suitable for polyamide hose DN | 14 |
