| Material | Polyamide |
| Seal | NBR |
| Protection class |
IP 54, IP 68 with additional O-ring, IP 69 K |
| Temperature range | -40°C to +100°C |
| Colour | black |
| RAL | 9005 |
| Variant | Metric |
| External thread (AG) | M16 |
| Cable diameter | 3 – 7 mm |
| D | 23 mm |
| Thread length (GL) | 8 mm |
| Height (H) | 40 mm |
| Wrench size (SW) | 22 mm |
| Suitable for polyamide hose DN | 10 |
