| Material | Nickel-plated brass |
| Seal | NBR |
| Material o-ring | NBR |
| Protection class | IP 68 - 1bar/30min |
| Temperature range | -20°C to +100°C |
| Variant | Metric |
| External thread (AG) | M90 x 2 |
| Cable diameter | 63 – 70 mm |
| Thread length (GL) | 15 mm |
| Height (H) | 42 mm |
| Wrench size (SW1/SW2) | 100/100 mm |
| Tightening torque | 140 Nm |
| Product group | Standard |
