| Material insulating body |
PA 6, PBT |
| Contact Ø | 0.6 mm│1 mm│2 mm |
| Nominal current data | 2 A |
| Nominal current signal | 8 A |
| Nominal current power | 28 A |
| Nominal voltage at degree of pollution 3 data | 60 V~ |
| Nominal voltage at degree of pollution 3 signal | 300 V~ |
| Nominal voltage at degree of pollution 3 power | 600 V~ |
| Temperature range | -40°C to +125°C |
| Degree of Protection | 3 |
| Minimum mating cycles | > 1000 |
|
|
||
|---|---|---|
