Material housing | Copper-Zinc alloy |
Material housing surface | Nickel |
Coding |
S, T |
External thread plug-in side | M12 x 1 |
Locking type | Screw |
Shield | unshielded |
Material seals/o-rings | NBR |
Flange | 25 x 25 mm |
Hole distance | 19.8 mm |
Hole diameter | 4 x Ø 2,7 mm |
Protection class |
IP 67, IP 69 K |
Temperature range | -40°C to +125°C |
