| Characteristic of connection | Crimp |
| Insert | Pin |
| Crimp contact | Crimp pin signal 0,6 mm machined |
| Material contact | Copper-zinc alloy |
| Material contact surface | nickel, gold plated (0.25 µm) |
| Contact-Ø data | 0.6 mm |
| Length (L) | 15.8 mm |
| Crimp range | 0.08 – 0.34 mm² |
| Suitable crimping tool | 7000900907 |
