| Housing type | Panel angled |
| Material housing | Zinc Die Cast |
| Material housing surface | Nickel |
| Installation type | Rear wall |
| Version |
Screw, TWILOCK, right angled |
| External thread plug-in side | M23 x 1 |
| Locking type | Screw |
| Shield | unshielded |
| Seal type | O-Ring |
| Material seals/o-rings | NBR |
| Rotatable | 330 ° |
| Flange | 25 x 25 mm |
| Hole distance | 19.8 mm |
| Hole diameter | 4 x Ø 3,2 mm |
| Protection class |
IP 67, IP 69 K |
| Temperature range | -40°C to +125°C |
