| Housing type | Coupler |
| Material housing |
brass, Zinc Die Cast |
| Material housing surface | Nickel |
| Version | Screw |
| External thread plug-in side | M23 x 1 |
| Locking type | Screw |
| Shield | shielded |
| Material seals/o-rings | NBR |
| Wrench size (SW1/SW2) | 24/24 mm |
| Cable diameter | 11 – 17 mm |
| Temperature range | -40°C to +125°C |
| Protection class | IP 67 |
| suitable contact inserts |
7001920107, 7003920101 |
