Material housing | Zinc Die Cast |
Material housing surface | Nickel |
Installation type | Rear wall |
External thread plug-in side | M23 x 1 |
Locking type | Screw |
Shield | unshielded |
Seal type | O-Ring |
Material seals/o-rings | NBR |
Panel hole | Ø 23 + 0,1 mm |
Flange | 26 x 26 mm |
Hole distance | 20.5 mm |
Hole diameter | 4 x Ø 3,2 mm |
Protection class | IP 67 |
Temperature range | -40°C to +125°C |
suitable contact inserts |
7001920108, 7003920102 |
